CHAPTER-1

INTRODUCTION

INTRA is the abbreviation of Industrial Training which is compulsory period of training for all semester 7 students  who already passed all subjects in 7 previous semesters. Industrial training (INTRA) is a training done in a real working environment with a specific task and permission assigned to the student by a company that to be accomplished during the period given. It is also one of the assessments to achieve the scroll. The industrial Training will be assessed on these aspects:

§ Company Supervisor Evaluation

§ Logbook

§ Report

§ Presentation

      Industrial training is a formal practical, which is conducted in a company that provides an industrial environment to the student. The practical works should be related to the course attained by student and approved by the Head of  Faculty. A student also should be given a constant supervision by an appointed supervisor (tutor) from the company.

      Industrial Training or otherwise known as INTRA is a compulsory semester that must be done by each and every student in order to complete their courses. Training can be done at any place or factory as long as it consists of the theory and practical technical skills.

     The period of the training must be completed in 3 and half months guided by a lecturer that acts as a University Supervisor thought out the training time.

To fulfill of this demand, the Industrial Training was completed throughout 16 weeks from 5^th July to 29^th October 2010.

      Thought out the training students are given work based on their current studies and supervised by a supervisor selected among the lecturers. At the same time students are also provided with Industrial Training Student Handbook & Logbook to take note on what they have been doing though out the training. The supervisor from University will make two times visit to the trainee’s place during the training to evaluate the trainee and hear any report or comment from the company supervisor. All problems, possibilities and works during the training should be report to both supervisors. It is compulsory to each trainee to complete their 16 weeks of training.

      This Industrial Training (INTRA) is one of the requirements for all University final semester students of respective course. The main objective of this INTRA is to give students vast exposure to a real industrial environment. Industrial training also leads the trainee to develop an independence, responsibility and creativity in a real working situation.

Trainee should be able to accomplish certain objectives:

• To apply the theoretically and practical knowledge gained from course taken in University
• To expose and practice the competency in a real working environment, this is different from the studying environment
• To apply the skills that they have gained throughout their academic years
• To be apart of the professional team in order to measure the human resource importance
• To give student opportunity to show and practice their skill and from that they get chance to attract the company to hire them after finish diploma
• To improve and gain more knowledge and skills
• To enhance their knowledge and abilities at the companies that they attached to
• To let student apply all theory learnt during the training
• To built self confidence
• To gain the capacity of solving variety of the problem and linking the theory with real situation in the company

 The Industrial Training had been completed in the CNN System (M) Sdn. Bhd (292173-W) which in located at Ara Damansara (head quarters office), and trainee attachment is in Sepang International Circuit as a technical. There, trainee job’s scopes are more to provide in overall electronic equipments system maintenance such as, track CCTV system, timing and info tower system, public address system, MATV (master antenna television system) network system and race control management system.

During this period the trainee was under Mr. Adam bin Mohd Salim, Project Manager and Mr. Amirudin Shukri bin Hussien, Supervisor.

This training also improve student communications skills when involve with a higher or lower level staff, and to build up trainee responsibility to the task given and exposes student more to create skills and gained a lot of experience followed by it job scopes.

Beside that, there are some subjects that can be applied during this industrial training such as job’s culture, communication, project management, maintenance field, arrange international event which in provide an electronics system, punctual or on time, and attitude.

CHAPTER-II

PRESENTATION OF CNN SYSTEM (M) SDN. BHD.

CNN SYSTEM (M) Sdn. Bhd. (292173-W)

No 5,Jln PJU 1A/20A

Ara Damansara,

47301 Petaling Jaya,

Selangor Darul Ehsan.

T: +603-7843 0700

F: +603-7843 0500

W: www.cnnsystem.com

Address attachment (site office)

CNN SYSTEM (M) Sdn. Bhd.

Sepang International Circuit,

Jalan Pekeliling.

64000 KLIA,

Selangor Darul Ehsan.

            CNN SYSTEM (M) Sdn. which based in Petaling Jaya is a progressive, forward thinking company that combines the traditional values of integrity, attention to detail and commitment to excellence, with innovation and advance technology. Provides the customer its innovative ideas, technical solutions and competence support towards the customer’s needs.

            CNN SYSTEM (M) SDN. BHD is fully ownership by Bumiputra status. This company is established on 11^th March1994 and Mohd Sobri Bin Omar, Siti Nursiha Binti Omar, Pauzi Bin Said, Ismail Bin Ibrahim, and Dato’ Mohd Salim Bin Abd Bari as a board of directors.

The company currently has about 50 employees. CNN System specializes in leading Technology Integrator for both wired and wireless digital systems in the field of Information, Communication and Technology (ICT). CNN System is a single source for consultancy, construction, equipment installation, commissioning and integration, preventive maintenance, as well as supplying telecommunication product. After a decade since it’s conception, CNN just recently ventured into Oil and Gas industry through the provision of infrastructure, vessels, and skilled manpower, specially for offshore service.

Under the ICT division, CNN itself have a vast experience in implementation, and integration. Among of the service offered are;

·         Consultancy services.

·         Outsourcing services.

·         System integration services.

·         Security surveillance system.

·          Software development.

·         Network design and implementation.

·         ICT infrastructure and site preparation.

·         Maintenance and support services.

In the interest of further focusing for the telecommunication field, CNN formed a subsidiary, CNE Sdn Bhd, offering cost-effective and targeted telecommunication infrastructure solution and services to leading operators in Malaysia.

Scopes of services;

·         GSM, GPRS/EDGE, UMTS, WiMax, WiFi network.

·         Point-point, point-multipoint microwave design.

·         Indoor and Outdoor WiFi/WiMax design.

·         Transmission network.

·         Indoor and Outdoor video surveillance system (web enable).

·         Implementation.

·         Ore network planning.

By establishing long term relationships with a vast number of renowned international reputable marine/offshore oil and gas companies, CNN System (M) Sdn Bhd is able to offer their clients the ideal vessel to suit any requirement.

            Scopes of services;

·         Pielay barge

·         Jack-up rig

·         Remotely operated vehicle (ROV)

·         Diving support vessel (DSV).

·         Shore approach/near shore.

·         Major and minor offshore installation.

·         Hook-up and commissioning work

Company’s vision;

·         To be the standard in group business and solutions in which all the competitors will compare against.

·         To create an environment conductive to a continuing happy relationship within the company, customer and supplier.

·         Our aim is not to sell products but services with products and being the partner of our client.

·         We always steadily pursue excellence and deliver more than we promised.

·         Making profit not from customer pocket but from customer savings on our provided solutions.

Company’s Mission;

      To be recognized as an innovator and leader in the global industries of ICT, TELCO, and OIL & GAS  industries. Always ahead of time, as solutions provider to our customers and business partners. The core values adopted

                  a) Ensure timely and accurate response on industrial needs at customer

                  b) Anticipating and feedback promptly to the inquiries of customer

                  c) Cost-effectively used of available resources

      Honesty, Integrity, Efficiency, Creativity, Flexibility, and Responsiveness are the ethics on which we were founded and have, in turn, attributed to our values. We will continue to provide our customers these same values to keep CNN SYSTEM (M) SDN. BHD ahead of time

This company legal status is private limited (Sdn. Bhd.). Private limited company is a company with its own profits, losses, assets and liabilities. Ownership of a private limited company is established through the division of shares. Private limited company is restricted from selling shares to the public. All private limited companies protect the associated officers or share holder from financial liability should the company encounter problems.

The CNN’s authorized capital is about five million Ringgit Malaysia and two and half million Ringgit Malaysia for the paid-up capital. For yearly informal profit range of this company is ten to fifteen million Ringgit Malaysia. But this profit depends on the project’s involvement.



CHAPTER-III

REPORT ON JOB

Description electronic equipment system maintenance services in Sepang International Circuit;

• TRACK CCTV SYSTEM.

Track CCTV system in Sepang Internasional Circuit is commonly use a fiber optic cable that directly proportional it will involve transmit (VDS2240 TX), receiver (VBS RX 2040), converter (VFM3000), and combiner (HFC 8 I /P TO 1 O/P) equipment. All thus are compulsory if associate with optical wave guide component system (OWG). This CCTV camera can be controlled at race control by using DATA PTZ CONTROLLER with pan, tilt and zoom (ptz) selection.

Receive video signal from CCTV pole that transmit by VDS2200 TX.

 This equipment will convert video signal into RF signal that can read by conventional television.

This device is function to minimize output flow into a single output when it input is more than one.

The VDS 2200 series offers a range of well as dual multimode versions and also even inside outdoor camera housings. Low-cost fiber optic video-data as a dual single-mode system. The VDS receivers are designed to be transceivers. Built-in automatic gain its bidirectional data interface makes the slotted into MC 11 power supply control (AGC) allows for plug and play VDS compatible with all types of cabinets. Stand-alone VDS models are to installation and maintenance-free cameras. (TTL, Current loop, be powered by PSA 12 DC adapters. For operation. Manchester, Bi-phase, etc) extreme environmental conditions a PSU The VDS transmitters come in stand- The very compact VDS 2200 transmitter 12 DC is recommended. Alone housings; the receivers are rack- is designed to be used over a broad the single-mode VDS 2240 receiver is mountable or stand-alone models (/SA). Temperature range and is there-fore SNM compatible. The VDS system is available in single as suitable for use close to a camera. The schematic diagram for the CCTV track is inclusive in appendix given.

Technical specification;

Video,

Video format PAL/SECAM/NTSC In-/output level 1 Vpp (±3 dB) Bandwidth (-3 dB) 8 MHz Differential phase <5° Differential gain <5% SNR Short link >60 dBw Over opt. budget >45 dBw Video connector(s) BNC 75 W.

Data,

Number of channels 1 Data interfaces RS-422/485 (2- and 4-wire) / TTL / current loop configurable Data format Full duplex, asynchronous, serial Data rate per channel DC to 64 Kbit/s Type of connector 2x 3-screw terminal.

Management,

LED status indicators   DC Power-on indicator (green)   CR Data carrier received   NV No video signal on in- or output Network management SNM  compatible (VDS 2240 RX only) SNM variables Voltages, module temp, alarm status e.a. (VDS 2240 RX only)



• MARSHALL TRAFFIC LIGHT SYSTEM.

This system is compulsory add in any circuit to make sure all the rider or driver will be inform if any incident happen through  the signal of light. If light red is generating, it mean circuit is close and when yellow light turn on, all rider or driver must be aware in term of safety precaution. When green light turns on, it means circuit is in normal condition. In Sepang International Circuit, all the Marshall traffic light are link together, which mean, there are eight  PLC (MITSUBISHI/MELSEC) where it located at each SE include at a Technic Room.

This PLC is link using a fiber optic cable and it will be converting using a HIRSHMANN converter. This entire PLC is generated by OMRON power supply. For the controller, it directly command from Race Control

This PLC is link using a fiber optic cable and it will be converting using a HIRSMANN converter. This entire PLC is generated by OMRON power supply. For the controller, it directly commands from Race Control. The schematic diagram for the Marshall Traffic Light is inclusive in appendix given.

• INFO TOWER SYSTEM.

This system is used to shows result to spectators and clock as well. Also use fiber optic cable as a data transmits. The data is key-in at the time keeping room using its own software.

For an introduction, Sepang International Circuit has three info towers that located at Roof Top Perdana, Support Paddock and Mall area. Each of them is directly control at Time Keeping Room using a single mode fiber optic and as a data transmitted. The data that sent from Time Keeping Room will be convert to signal that will be read by PCB board appropriately ±3Vdc. For the hub to this system, Technic Room will collect all the data (fiber optic) and send of all three info tower.

• PUBLIC ADDRESS SYSTEM (PA).

In Sepang International Circuit, there have a lot of speaker that followed by it type which in, pole speaker and grandstand speaker.

            It starts from 12 channel mixer at speaker room that is use by commentator to speech and          make an announcement.

From there, a two core signal cable is directly to Technic Room and connects on it TOA ZONE

SELECTION

 TOA's VM-2240 management amplifier has been designed for paging and BGM, where zone selection is required. The VM-2240 features Power: 240W / 100V line output, 3 x Microphone/ Line inputs, 2 x BGM inputs and 1 x Telephone paging input, 5 x zone selection, programmable hierarchy of priorities available, 6 x built in chimes and output level control. In addition the VM-2240 is expandable to 40 zones utilizing 8 amplifiers. Applications for the VM-2240 include clubs, hotels, factories and retail outlets. An optional surveillance board (SV-200M), optional remote microphone (RM-200M) and an optional voice announcement board (EV-200) are also available.

From TOA VM-2240, sound signal will increase at SQ45 Amplifier.  The SQ45 range of public addresses ‘high performance audio power amplifiers’ has been designed to fulfill most professional public address requirements. To make sure it will be enough carry signals to the long distance. For the   Grandstand K, F, G hill and D hill, audio signal is transmit by OT SYSTEM (fiber optic converter).

• OWG (OPTICAL WAVE GUIDE) COMPONENT SYSTEM (SPECIAL EXCHANGE-SE).

For example, in Sepang International circuit itself, there have 27 CCTV along it track and two or more are located at any turn. The distance from race control (monitoring) to CCTV is about 500 meters to 5 kilometers and this fact shown, it must use special equipment or device to carry out the data and the video signal with smooth handling without much data looses.

In the beginning, coaxial cables are widely used to carry signal data in any distance, but, there are many looses occurred. For the solution, fiber optic cables are efficiency in all aspect inclusive time to install, pinch or save space in term of diameter measurement, and the most important is, less data loss compare using a coaxial cable.

The principal of an optical fiber is a thin, flexible, transparent fiber that acts as a waveguide, or "light pipe", to transmit light between the two ends of the fiber. The field of applied science and engineering concerned with the design and application of optical fibers is known as fiber optics. Optical fibers are widely used in fiber-optic communications, which permits transmission over longer distances and at higher bandwidths (data rates) than other forms of communication. Fibers are used instead of metal wires because signals travel along them with less loss and are also

Immune to electromagnetic interference. Fibers are also used for illumination, and are wrapped in bundles so they can be used to carry images, thus allowing viewing in tight spaces. Specially designed fibers are used for a variety of other applications.

Fibers which support many propagation paths or transverse modes are called multi-mode fibers (MMF), while those which can only support a single mode are called single-mode fibers (SMF). Multi-mode fibers generally have a larger core diameter, and are used for short-distance communication links and for applications where high power must be transmitted. Single-mode fibers are used for most communication link longer than 1,050 meters (3,440ft)

The material of Glass optical fibers are almost always made from silica, but some other materials, such as fluorozirconate, fluoroaluminate, and chalcogenide glasses as well as crystalline materials like sapphire, are used for longer-wavelength infrared or other specialized applications. Silica and fluoride glasses usually have refractive indices of about 1.5, but some materials such as the chalcogenides can have indices as high as 3. Typically the index difference between core and cladding is less than one percent.

Plastic optical fibers (POF) are commonly step-index multi-mode fibers with a core diameter of 0.5 millimeters or larger. POF typically have higher attenuation coefficients than glass fibers, 1 dB/m or higher, and this high attenuation limits the range of POF-based systems

• MATV (MASTER ANTENNA TELEVISION SYSTEM) NETWORK SYSTEM.

MATV network system is a one of the important system that gets at Sepang International Circuit. The ability of this system is to bring broadcast signal from outsider into a SIC and convert the entire video signal to RF signal. Almost all the equipment that interconnected in MATV system is use equipment from Fracaro. Among them, Fracaro MBJ3631 antenna amplifier, Fracaro Agile Channel Processor,  Fracaro Headline Audio Video Modulator and Fracaro Spiltter and Tap.
This MATV network system is beginning from roof top Perdana Suites, where it located two antennas which in, VHF ANTENNA BLV6F and UHF ANTENNA BLU420F. From this antenna, RF signal is carry by RG-6 BELDEN 9116S cable and through a lighting arrestor to avoid from surge.  The two of antenna will be combining in FRACARO MBJ3631 Antenna Amplifier and produce one output.

This combine signal (RF) is directly connected to lighting arrestor at Technic Room (SE Central) and to FRACARO AGILE CHANNEL PROCESSOR.

This frequency agile channel processor capable of converting any VHF, UHF, or CATV input signal to any standard output channel between 54 through 550 MHz. Input and output frequency, including output frequency offset, are easily set with front panel push wheel switches. After all, the entire process channel will distribute to others area by using an amplifier and splitter. All the schematic diagram is inclusive in appendix given.

• UNINTERRUPTABLE POWER SUPPLY (UPS)

An uninterruptible power supply, also uninterruptible power source, UPS or battery/flywheel backup is an electrical apparatus that provides emergency power to a load when the input power source, typically the utility mains, fails. A UPS differs from an auxiliary or emergency power system or standby generator in that it will provide instantaneous or near-instantaneous protection from input power interruptions by means of one or more attached batteries and associated electronic circuitry for low power users, and or by means of diesel generators and flywheels for high power users. The on-battery runtime of most uninterruptible power sources is relatively short—5–15 minutes being typical for smaller units—but sufficient to allow time to bring an auxiliary power source on line, or to properly shut down the protected equipment.

While not limited to protecting any particular type of equipment, a UPS is typically used to protect computers, data centers, telecommunication equipment or other electrical equipment where an unexpected power disruption could cause injuries, fatalities, serious business disruption and/or data loss.

JOB’S SCOPE;

1.      Track CCTV system.

Field CCTV pole camera;

·         Clean exterior camera housing camera.

·         Clean housing body glass window.

·         Clean and lubricate if necessary PTZ (pan/tilt/zoom) head.

·         Clean and check external housing of receiver unit.

·         Check camera status to race control.

·         Check and inspect loose cables and terminations re-terminate if necessary, especially RG6 coaxial cable.

·         Check and inspect fiber optic transmitter for video and data.

·         Check fiber optic transmitter functionality.

·         Check power supply unit.

·         Check functionality of pan, tilt and zoom functions.

Race control room and SE central;

• Check and verify power supply and indicator at video matrix.
• CHECK AND VERIFY FUNTIONALITY of each camera signal at each input of the input video matrix.
• Check and verify functionality of pan, tilt and zooming function for each track CCTV camera.
• Check and verify functionality of each 21 inch array monitors.
• Brightness
• Contrast.
• Chroma.
• On/off switch.
• Display quality.
• Check and verify functionality of time lapsed VCR unit.
• Head cleaning.
• Play back function.
• Recording function.
• Rewind and forward function.
• Video quality.
• Remote control function.
• Check and verify controller keypad functionality for its camera switching and PTZ facilities.
• Check and verify and loose cables and terminations.

2.      PUBLIC ADDRESS SYSTEM.

All SE outdoor cabinet SE01 to SE08 and pole loud speaker;

• Check power amplifier (PA) functionality.
• Check and verify audio signal transmission from speaker room.
• Check and verify output from each PA.
• Check and verify audio fiber receiver module.
• Check and verify each pole loud speaker correspond to each PA.
• Check and inspect loose cables and termination.

Speaker room and SE central;

• Check and verify the functionality of 12 channel audio mixer.
• Check and verify the functionality of the wireless microphone system.
• Check and verify the functionality of 4 channel headphone mixer.
• Check and verify the functionality of 4 channel audio mixers dedicated for

commentator.

• Check and verify the functionality of Commentator headset.
• Check and verify audio signal quality at speaker.
• Check and verify functionality of matrix zoning distribution unit.
• Check and verify that designated zones correspond to the matrix zoning.

3.      TIME KEEPING ROOM

Timing system detection unit, coupler unit, timing server, info tower distribution unit and power distribution unit.

·         Check and inspect timing detection unit functionality.

·         Check and inspect main timing server PC main and backup functionality.

·         Verify timing server software communication link.

·         Check and verify looping cable connectivity functionality.

·         Check and verify functionality of info tower display distribution unit.

·         Check and verify communication link between PC and info tower distribution unit.

·         Check and verify output signal to all info tower.

·         Check and functionality of UPS power supply unit.

·         Check and verify functionality of 9 inch video monitor.

4.      MARSHALL TRAFFIC LIGHT SYSTEM.

SE outdoor cabinets SE01 to SE08.

• Check and verify power supply to PLC system.
• Check and verify functionality of CPU module.
• Check and verify functionality of input module.
• Check and verify functionality of communication RS485 module.
• Check and verify functionality of fiber optic communication module.
• Check and verify functionality of each bulb lamp.
• Check and verify equipment functionality by generating red and yellow light signal from race control and verify output at designated traffic light.
• Clean and vacuum exterior PLC assembly from any access dust and pest waste drooping.

SE central and race control room.

• Check and verify power supply to master unit PLC system.
• Check and verify functionality of master unit module.
• Check and verify functionality of input modules.
• Check and verify functionality of output modules.
• Check and verify functionality of communication RS485 module.
• Check and verify functionality of fiber optic communication module.
• Check and verify equipment by generating red and yellow light signal from race control room.
• Check and verify function of the graphical operator terminal (GOT) unit.

5.      MATV NETWORK SYSTEM.

Trunk distribution RF amplifier, headline modulator unit, terrestrial antenna unit UHF

and VHF and MATV network distribution.

SE Central room.

• Check and verify power supply unit 63Vac functionality for self power trunk amplifier unit.
• Check and verify functionality of headend amp 1, headend 2, paddock club amp, pit wall amp, pit building amp, medical centre, commentator booth mall area amp by measuring its output RF signal so that is maintained at 70-80 dbuV.
• Check and verify RF signal availability at pit building are which inclusive of media centre area, paddock club 1 to 4, media area, pit area, pit wall, VVIP perdana suites area, race officials  offices, race control room, time keeping room, speaker room, hospitality area, winners podium area, medical centre complex, marcee area, team common room, support paddock south track, welcome centre complex, corporate suite and commentator booth.
• Check and verify functionality of UHF and VHF terrestrial antenna unit.
• Check and verify UHF and VHF antenna alignment.
• Check and verify all local transmitted tv signal strength.
• Check and verify functionality of each agile modulator input and visual inspect the desired channel at tv screen.

 RF outlet end and tap-off – all area.

• Check and verify RF signal for availability at all TV’s end by inspecting that all tv channel which are broadcasted from SE Central is achievable at all tv’s screen. Measured signal at tv input much be around 70 to 80 dbuV.
• Check and inspect all LCD TV functionality at all area i.e: channel searching selector and audio volume adjustable.
• Check and verify the condition of all TV distribution taps for its loose cabling and terminations.

6.      OPTICAL WAVE GUIDE (OWG) COMPONENTS AND FIBER CABLE NETWORK

Special equipment (SE) outdoor cabinet video

• Check and verify the functionality of optical video frequency modulation (VFM) transmitter module.
• Check and verify the functionality of optical video combiner distribution module.
• Check and verify the functionality of optical video AWS transmitter module.
• Check and verify the functionality of optical video receiver module.
• Check and inspect for any loose cable and terminations.
• Check and verify the functionality of rack mount distribution unit.
• Power supply.
• Ventilation fan unit.

Audio;

• Check and verify the functionality of optical audio receiver unit.
• Check any inspect for any loose cable and terminations.

Marshall traffic light system;

• Check and verify the functionality of optical data transceiver module.
• Check and verify power supply distribution unit to data transceiver.
• Check and inspect for any loose cable and terminations.

Uninterruptible power supply (UPS);

·         Check and verify the functionality ups system.

·         Manual offline shutdown, verify the status battery back-up.

·         Check and inspect the UPS LED display panel for any error.

				File No: CNN/SIC-F1/IR/092512-02
EXAMPLE OF INCIDENT REPORT FORM
Contract Number: SIC/PCD/CA/02/2005/1		Project Title:		Issue Date: 5.7.2010
		OPERATION MAINTENANCE AND SUPPORT OF ELECTRONICS   EQUIPMENTS AT SEPANG INTERNATIONAL CIRCUIT		PREPARED BY: Adam Mohd Salim Project Manager
INCIDENT REPORT
Equipment: INFO Tower – Mall Area (Time Keeping System) Model: 1)      Vmaster.PCB Master Controller Card 2)      Vsctr.PCB – Slave Controller Card 3)      LBPdrv.PCB – LCD Display Card S/Number: Quantity:			Location: 1)      Mall Area – Main Grandstand 2)      Support Paddock 3)      Pit Building	Distribution: Zainal Frederick Zakaria  - CNN System Siti Nursiha Omar – CNN System Abdul Rahman Khalid En. Azhar Abdul Rahman - SIC
				REVISION:	01
Fault Reported Date:	25th. June.2010		Action Taken Date:	25th. June. 2010

DESCRIPTION

ACTION TO BE TAKEN

INFO TOWER SYSTEM i)        Mall Area (Main Grandstand Area) - At this current  moment the INFOTower Display for all three sides are faulty. Communication from the Time Keeping System is unavailable. - Electrical Distribution Panel Board that served the this Info Tower is in unhealthy conditions. Sparks and sounds produced by the MCB’s while switch on the unit. -            ii)                  PIT Building - Controller Card and its associated unit are in bad condition due to exposed to weather and outdoor. - Electrical Distribution Panel Board that served the this Info Tower is in unhealthy conditions. Sparks and sounds produced by the MCB’s while switch on the unit. -            iii)                Support Paddock - Controller Card and its associated unit are in bad condition due to exposed to weather and outdoor. - Electrical Distribution Panel Board that served this Info Tower is in unhealthy conditions. Sparks and sounds produced by the MCB’s while switch on the unit.

- Controller Card and it associated unit are faulty. ·          Master Controller Card ·          Slave Controller Card ·          LCD Drive Card - Immediate attention required against the Electrical Distribution Panel for all three locations : - ·          Pit Building ·          Mall Area ·          Support Paddock Immediate replacement to the faulty units needed with new sets before the motoGP 2010 - Delivery of the above item takes 3 to 4 weeks due to local assembly (made to order). Conditions of all Info Tower System are at unhealthy state. Equipment breakdowns are anticipated to occur any time due to equipment life-time working conditions.

	CNN SYSTEM	SIC
VERIFIED BY: SIGNATURE: DATE:

Figure 47: Example of incident report form.

TRAINEE ON DUTY;

v  Re-installation old PHILIPS CCTV track (cam 8) to substitute a new SAMSUNG CCTV for a temporary time and trainee was duties to compare the two CCTV and take an observation about it result.

After all, trainee fined that, a new SAMSUNG CCTV was more clearly, and more precise when zoom in and zoom out. Beside that, this cam came with build in lens compare with PHILIPS CCTV that separately purchase.

   v  Doing a troubleshoot on info tower perdana suite regarding their connector on receiver card   and line no 4 from above is faulty or error to function as usual. This task is commonly a high importance task because it will be used on Merdeka Millennium Endurance Race (MME).

For the beginning, trainee check all the connection on its master card and the result is positive, all the connection is proper tight. After that, trainee tries to change all the connection to other port and side three info tower perdana still in malfunction.

For the second step of our task, trainee rectify where it input data incoming and after all, trainee get that UTP cable from fiber optic data converter is wrong connection with the receiver PCB board by using a Multimeter. After trainee and his group were fix it/occur a troubleshoot, info tower act as normal.

On this task, trainee was realize that, when do a troubleshoot, all aspect must to be consider and can’t miss a certain-certain part and follow a right way to prevent a bad things.

v  After trainee and his group do a routine check, they find that no audio output is being transmitted to G Hill and directly proportional unable to achieved audio sound at G Hill. At the moment, trainee goes to SE03 (audio system is directly transmitted by using a fiber optic cable from Technic Room to this SE to control sound system at G Hill area only) to make sure all the SQ45 Amplifier was turn to on. Trainee gets that all the SQ45 is on.

For a while, trainee makes a further checking on the SQ45 Amplifiers. Audio source from a walkman is inserted to the main line of the Amplifiers. Audio sound is available. Amplifiers are in working condition.

Further checking to the Audio converter (OS SYSTEM) which transmits the audio signal from Technic Room. Visual inspection to the Audio converter and found that the converter is faulty with burn marks on its internal circuitry It is confirmed that the converter is faulty

A new replacement is required in order to have audio facilities to G Hill area and a Transmitter and Receiver unit in pair is required for the above exercises.

The converter need to be service and repair at its authorized repair centre or new replacement needed. Purchase order (PO) for the replacement will follow later.

CHAPTER-IV

CONCLUSION AND RECOMMENDATION

CONCLUSIONS

The Industrial Training provided very good exposure and knowledge to the students and also to enhance the communication and problem solving skills to the students. Furthermore the students also learned to be adapted to the working environment. From the industrial training at CNN SYSTEM (M) SDN. BHD, the trainee found that:

• Exposure to the real working environment makes me a more responsible person and had a chance to improve my communication skills and self-confidence.
• Enhance problem solving skills which can be used in future in the real working life especially to counter the problems.
• In the new job’s enviroment, trainee find that, it is important to responsible in all that task given and take care of attitute to make sure it will produce a good first prespective to trainee.

After four months it can be said the industrial training was successful and achieved their objectives. Here, the knowledge that trainee get did not come only from books, but skills and experience from the people around. For the whole training period, it is a useful experience and knowledge to trainee to be adapt now and in near future. The study environment and working life is much different where by in working environment the workers should communicate more to others in order to solve the problem.

RECOMMENDATION

During involved in preventive maintenance at Sepang International Circuit, trainee gets that bureaucracy system is hinder to us for doing a task. Many scope’s job are stuck cause by this system and a priority or high status job cannot to be progress and waiting for a month to fix it up.

This situation must to prevent or dodge to make sure all the system in good condition and increase duration of life upon the system.

The bureaucracy that trainee mean is, hard to get a certain-certain spare parts that use to fix a malfunction system and wait until two month for the approval.

Picture below shown the bureaucracy causes;

This CCTV SECURITY SURVEILLANCE SYSTEM is unnecessary to fix it problem because scarcity spares part. For this system, trainee gets that it data converter is faulty and it controller PCB board is burn out. Purchase order for the replacement was done about one month later but still not responds from the MIS department. Before that trainee was spoke adverse a high status task, and this Security Surveillance System is one of it. This fact was occurred in specific condition in term of security means.

From all of this, trainee is recommend to bring into existence one department that only have control of matters interconnected on mechanical, electrical and electronic equipment for it through hospitality.
